Inserts
Knurled, helical and ultrasonic inserts for plastics that hold.
Overview
A brass insert is judged by two failures it must never have: pull-out and rotation. Rajhans manufactures straight-knurled, diamond-knurled, helical and ultrasonic inserts with crisp, full-depth knurls and concentric bores that seat true in the mould.
We supply moulders of PPR/CPVC pipe fittings, electrical accessories and engineering plastics across India and export markets, in standard metric series or fully custom geometries to drawing.
Typical Applications
- PPR / CPVC / UPVC pipe-fitting inserts
- Ultrasonic and heat-staking inserts for plastics
- Electrical accessory inserts
- Press-fit and mould-in bushes
- Self-tapping threaded inserts
Specifications
| Material grades * | CW614N (CuZn39Pb3), CW617N, IS 319 Grade I/II |
|---|---|
| Size range * | Ø3 mm – Ø65 mm bar stock |
| Threading * | BSP, BSPT, NPT, Metric, UNC/UNF — gauged |
| Tolerance * | Up to ±0.01 mm on critical dimensions |
| Finishes * | Natural, nickel, tin or chrome plating; deburred & polished |
| Thread sizes * | M2 – M12 internal; 1/8" – 1" BSP |
| Knurl patterns * | Straight, diamond, helical — full-depth |
* Indicative specification — confirm against your drawing.
Product Gallery
Have a drawing in this category?
Send it across — our engineers reply with pricing, lead time and manufacturability feedback within 24 working hours.
